It is about 0.05~20cc and is suitable for metered discharge of about 5,000~50,000cps.
Menu
It is about 0.05~20cc and is suitable for metered discharge of about 5,000~50,000cps.
| A. Pump head | SUS316 |
| B. Rotary valve | Zirconia Ceramic |
| C. Spacer | PTFE、POM |
| D. O-ring | EPDM, FKM, Silicone, CR, FFKM, Kalrez ®, BUNA |
| E. Plunger | Borosilicate Glass, SUS316, Zirconia Ceramic |
| F. Nozzle | SUS316、POM |
| G. Plunger Seal | Outside: PTFE, UHMW-PE Inside: EPDM, FKM, Silicone, CR, FFKM, Kalrez ® |
| H. Headliner | PTFE、POM |
* Kalrez® is a trademark or registered of DuPont Corporation or its affiliates.
List of Models
|
MODEL
|
Outer diameter dimension (mm)*1 |
Weight (kg)*1
|
Maximum discharge rate (cc)
|
||
| Length | Width | Height | |||
| 1SR2S-□□□□ |
(230)
|
85
|
88
|
3.2
|
～0.05 |
| 1SR3S-□□□□ | ～0.11 | ||||
| 1SR3M-□□□□ | ～0.23 | ||||
| 1SR4M-□□□□ | ～0.40 | ||||
| 1SR5M-□□□□ | ～0.63 | ||||
| 1SR7M-□□□□ | ～1.23 | ||||
| 1SR10-□□□□ | ～2.51 | ||||
| 2SR8R-□□□□ |
(280)
|
91
|
94
|
4.1
|
～3.22 |
| 2SR10-□□□□ | ～5.03 | ||||
| 2SR12-□□□□ | ～7.24 | ||||
| 2SR14-□□□□ | ～9.85 | ||||
| 2SR17-□□□□ | ～14.52 | ||||
| 2SR20-□□□□ | ～20.11 | ||||
*1 Reference dimensions and weight excluding motor.
