The pressure tank TP series is ideal for small capacity and it can be fixed onto equipment with its tank holder. It is suitable for small volume dispensing application.
|
Model
|
TP300
|
TP500
|
TP700
|
|
Tank Capacity
|
300cc
|
500cc
|
700cc
|
|
Weight
|
1.3kg
|
1.5kg
|
1.7kg
|
|
Material
|
SUS304
|
||
|
Operating Pressure
|
Maximum 0.49MPa
|
||
|
Lid Attach / Detach Mechanism
|
Ferrule clamp type
|
||
|
Fluid Outlet
|
Rc1/4
|
||
|
Sealing Method
|
O-ring seal (NBR standard)
|
||
|
Finish
|
Buffing of the inside and outside surface
|
||
Other than the standard NBR, the materials in which the O-ring is available are FKM, silicone, EPDM, FFKM, FEP/SI double O-ring etc. Please select the one which suits the material you are using.
